Features and Benefits
- Compact design: small and compact standalone product, no additional components needed, Plug-and-play
- CAT5/CAT5e compatible
- Integral mounting bracket
- Operating voltage: data 5V, PoE 48V
- Clamping voltage: 70V
- Maximum surge discharge current: 10KA (8 to 20uS)
- Peak pulse current: 100A (10 to 1,000uS)
- Pin protected: all 8 pins (signal pairs and spare pairs)
- Protection mode: differential and common mode
- Insulation impedance: >1,000MΩ
- Data rate: Ethernet 10Gbps, PoE 5Gbps @ CAT6A 90m (pin to pin)
- Impulse protected voltage: <650V
- Response time: <5nS
- Operating temperature: -40 to 85°C
- Storage temperature: -40 to 85°C
- Dimensions: 83 x 25.4 x 25.4 mm
- Weight: 80g
- Ground lug wire: 14AWG
